Benefits & Features: Excellent for applications with fluctuating or multiple viscosities - No field calibrating required; Accuracy: ± 1% Of Reading; Up to 1,000 cps Viscosity; No straight pipe requirements; Bi-directional; PPS Rotors are immune to galling (adhesive wear); PPS Rotors produce less noise than metal rotors

Max Pressure Drop (at Max Flow in test conditions): Contact us

Accuracy (% of Reading) Factory Calibrated with Computer: ± 1% @ 3cp

Repeatability (based on test conditions): ± 0.03%

Maximum Viscosity: 1,000 cps

Recommended Strainer Size: 200 Mesh (75 Microns)

Max. Particle Size: .003" / .074 mm

Operating Temp Without Local Computer or With Remote Computer: 5 to 176°F (-15 to 80°C)

Bearings: None

Shaft: Stainless Steel

Rotor: PPS

Seals: PTFE encapsulated FKM

Typical K-Factor PPG (PPL): Reed: 1345 (355), Hall Effect: 2690 (710)

Local Module & Output Signal: Open Collector (NPN) Unscaled Pulse

Remote Output: None

Sensor (Pickup): Reed Switch / Hall Effect<br>[Hall Effect Sensor requires dedicated power source]

Application Notes: The meter may be mounted horizontally or vertically but must be mounted, so the rotor shafts are in a horizontal plane (see manual), For viscous liquids, the maximum allowable flow may need to be reduced to ensure the pressure drop across the meter does NOT exceed 15 PSI, Viscosities <3cps, min. flow range is 10% of the maximum flow range, Line must be full (no air) for proper accuracy

Connection to Connection Length (OAL): 2.91" (74mm)

Shipping Weight (Approximate): 3 lbs (1.4 kg)

Approvals Notes: CE Approval is applied when meter is part of a system
