Benefits & Features: Excellent for applications with fluctuating or multiple viscosities - No field calibrating required; Accuracy: ± 0.5% Of Reading; Up to 1,000,000 cps Viscosity; No straight pipe requirements; Bi-directional; SS Rotors are very stable with increasing temperatures

Max Pressure Drop (at Max Flow in test conditions): Contact us

Accuracy (% of Reading) Factory Calibrated with Computer: ± 0.5% @ 3cp

Repeatability (based on test conditions): ± 0.03%

Maximum Viscosity: 1,000,000 cps

Recommended Strainer Size: 100 Mesh (150 Microns)

Max. Particle Size: .006" / .149 mm

Operating Temp Without Local Computer or With Remote Computer: 5 to 250°F (-15 to 120°C)

Housing Material: 316LSS

Bearings: Carbon Ceramic

Shaft: Stainless Steel

Seals: PTFE encapsulated FKM

Rotor: 316SS (Hi Viscosity)

Typical K-Factor PPG (PPL): Reed: 53 (14), Hall Effect: 212 (56)

Local Module & Output Signal: Open Collector (NPN) Unscaled Pulse

Remote Output: None

Sensor (Pickup): Reed Switch / Hall Effect<br>[Hall Effect Sensor requires dedicated power source]

Applications (always check Chemical Compatibility Guide): Metering clean fluids such as water based liquids for Chemical, Cosmetic, Food, and Pharmaceutical Industries

Not Suitable For Applications: Dirty liquids

Minimum Straight Pipe Dia.s: None

Desired Straight Pipe Dia.s: None

Application Notes: The meter may be mounted horizontally or vertically but must be mounted, so the rotor shafts are in a horizontal plane (see manual), For viscous liquids, the maximum allowable flow may need to be reduced to ensure the pressure drop across the meter does NOT exceed 15 PSI, Viscosities <3cps, min. flow range is 10% of the maximum flow range, Line must be full (no air) for proper accuracy

Connection to Connection Length (OAL): 7.4" (188mm)

Shipping Weight (Approximate): 25 lbs (11.3 kg)

Approvals Notes: CE Approval is applied when meter is part of a system
